Material and treatment (frame)
Painted mild steel
Frame is made from painted mild steel. The bearings and drive/idle rollers are from mild
steel
Stainless steel
Frame is made from stainless steel AISI304. The bearings and drive/idle rollers are from
mild steel
Zinc sprayed painted mild steel
Frame is made from sandblasted, zinc sprayed and painted mild steel.
The bearings and drive/idle rollers are from mild steel
Material and treatment (plating)
Zinc plated steel
The plating is made from zinc plated steel
Stainless steel
The plating is made from stainless steel AISI304
Drum shape
Round
The drum is round shaped
Octagon
The drum is octagon shaped
Drum
U-profile gap 10 mm
The drum is made from stainless steel AISI304, u-profile with gaps 10 mm
Perforated plate round 12 mm
The drum is made from stainless steel AISI304, perforated plate with rounds 12 mm
Perforated plate slot 12 × 40 mm
The drum is made from stainless steel AISI304, perforated plate with slots 12 × 40 mm
Material (cleats)
Stainless steel
The cleats are made of stainless steel AISI304
Cleats shape
Straight
The cleats are straight shaped
Turned
The cleats are shaped turned
Material (product conveyor)
Mild steel
The product conveyor is made from mild steel, covered with rubber.
The cleats height is 50 mm. The gap size is 5 mm
Stainless steel
The product conveyor is made from stainless steel AISI304, covered with rubber.
The cleats height is 50 mm. The gap size is 5 mm
PVC
The product conveyor is made from PVC. The cleats height is 60 mm
Destoner*
Drum
While the produce floats, stones and dirt sink to a stone conveyor at the back of the
machine
Material and treatment (stone conveyor)*
Mild steel
The stone conveyor is made from mild steel.
The cleats height is 40 mm.
The gap size is 10 mm
Stainless steel
The stone conveyor is made from stainless steel AISI304.
The cleats height is 40 mm.
The gap size is 10 mm
Jackscrew*
Jackscrew
Dirt sinks down and is taken out by a jackscrew at the bottom of the machine
Leaf separator*
Leaf separator
At the end of the machine a leaf separator takes out all floating debris
Electrical control
No electric
Motors and necessary sensors
Stand-alone
Motors, necessary sensors and control panel.
The length of the cable is 5, 10, 15 or 20 meter
Central control in line
Motors and necessary sensors
Material and treatment (electrical panel)
Painted mild steel
The electrical panel is made from painted mild steel
Stainless steel
The electrical panel is made from stainless steel AISI304
Water management
Manual
The valves can be operated manually. The water level must be regulated manually
Automatic
The valves are operated automatically. The water level is regulated automatically
Cleaning*
Spray tube product conveyor
A spray tube is included to clean the produce
Adjustment drum valve
Manual
The outlet valve can be adjusted manually
Automatic
The outlet valve can be adjusted automatically
Material and treatment (subframe)*
Painted mild steel
It is made from painted mild steel
Stainless steel
It is made from stainless steel AISI304
Galvanized steel
It is made from galvanized steel
Height of subframe*
Height of subframe
0 to 3 meter
